Multi Channel Low Side Driver
NOVOSENSE multi-channel low-side drivers focus on intelligent low-end driver solutions, providing a variety of different channels and current options, supporting 12V and 24V application scenarios in harsh environments, with the highest withstand voltage of 55V. Fully qualified and equipped with protection features and enhanced diagnostics, the products can be used in industrial automation and automotive applications.
View All Products
show 3 devices
| Part Number | Load Type | Driver Type | Rds (on) (LS) mΩ | Peak Current (A) | Number of Low-side Channels | Vmin(V) | Vmax(V) | Control Interface | Feature | Operation Temperature (°C) | Qualification | Package | LDO |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NSD5604-DHTSPR | Relay/solenoid | Fully-integrated low-side driver | 260 | 3 | 4 | 8 | 55 | Parallel | Over-current protection, over-temperature protection, under-voltage protection, clamp | -40~125 | Industrial | HTSSOP16 | NO |
| NSD5604N-DHTSPR | Relay/solenoid | Fully-integrated low-side driver | 260 | 3 | 4 | 8 | 55 | Parallel | Over-current protection, over-temperature protection, under-voltage protection and clamp | -40~125 | Industrial | HTSSOP16 | YES |
| NSD5604N-Q1HTSPR | Relay/solenoid | Fully-integrated low-side driver | 260 | 3 | 4 | 8 | 55 | Parallel | Over-current protection, over-temperature protection, under-voltage protection and clamp | -40~125 | Automotive | HTSSOP16 | No |
For more product information, please contact us.
